Electrical:
Number of Poles: 1P, 2P, 3P
Conforms to standard of: IEC/EN60898, GB10963-99
Rated Voltage (UE): AC 240/415V
Rated Frequency: 50/60Hz
Rated Current (In): 1,2,3,4,6,10,16,20,25,32,40,50,63A
Rated Breaking Capacity (ICN): 6KA IEC898(1-63A) (Techno)
Tripping Characteristics: B,C,D
Max. Connecting Fuse: 100A gl (>6K A)
Working Ambient Temperature: -5 to +40°C
Degree of Protection: IP40 (After Installation)
Electrical Life: Not Less of 8000 times swithing operation
Mechanical Life: Not less of 2000 times switching operation

Mechanical:
Exposed face length: 45 mm
Device Height: 80 mm
Device Width: 17.5 mm per pole
Installation Mode: Easy mounting onto 35mm DIN rail
Terminals Mode: Two-function terminal can connect with busbar & Conducting wire
Terminal Connecting Capacity: Busbar:1-25mm2, Conducting wire 0.8-2mm
